تفاصيل المنتج:
شروط الدفع والشحن:
|
| القدرة المقدرة: | 4 طن | الوزن التشغيلي: | 13000 كجم |
|---|---|---|---|
| سعة الجرافة: | 2.3 م 3 | محرك: | ويتشاي |
| نموذج المحرك: | WP6G175E22 | قوة المحرك: | 129 كيلو واط/2200 دورة في الدقيقة |
| نوع التحول: | التحكم في نقل الحركة الميكانيكية | نوع النظام الهيدروليكي: | التحكم في العمل بعصا التحكم (ذراع واحد) |
Top Brand Wheel Loader Manufacturer
200,000 Units More Working Worldwide
Pay Loader, Chinese Pay Loader, Chinese Wheel Loader, Chinese 3T Wheel Loader, Chinese 5T Wheel Loader,
Chinese Large Wheel Loader, Chinese Small Wheel Loader, 1T-2.3T wheel loader
Cummins Engines and ZF Transmission & Axles
Pilot Control System, Automatic Leveling
Complete line of applications and accessories
Easy maintenance & Outstanding After-sales
Top brand quality, reliable and save 20% plus
| CONFIGURATION |
| WEICHAI Engine |
| Lonking Transmission |
| Mechanical powershift control |
| Lonking axles (dry type) |
| Joystick working control (single -lever) |
| Flexible shaft controlled caliper brake |
| standard lift & bucket 3m3 |
| ROPS* FOPS cabin |
| Mechanical instrument panel |
| Air conditioner |
| TECHNICAL PARAMETERS | ||
| Basic | Bucket capcity | 2.3m3 |
| Rated payload | 4000kg | |
| Operating weight | 13000±300kg | |
| Traction force | 120±3kN | |
| Breakout force | 115±3kN | |
| L*W*H | 7270*2800*3300mm | |
| Engine | Manufacturer/Model | WEICHAI / WP6G175E22 |
| Rated power | 129kw/2200rpm | |
| Rated torque | 700N.m/1300rmp-1500rpm | |
| Bore * Stroke (mm) | 105*130mm | |
| No.of cylinders /Displacement | 6/6.75L | |
| Compression ratio | 17 | |
| Air cleaner | Three stage air cleaner | |
| Alternator | 70Amp | |
| Baterry | 2-24V/105Ah | |
| Starting motor | 24V/6kW | |
| Drive train | Transmission type | Planetary powershft tranmission |
| Shift Type | Mechanical powershift control | |
| Pressure of transmission | 1.1-1.5MPa | |
| Torque converter | Single-stage &duo- turbine ,4 element | |
| Axles | Rigid (front)& Oscillating (Rear) | |
| Rear axle Oscillation (°) | ±10° | |
| Differential | Conventional | |
| Main reducer | Spiral bevel gear 1-stage reduction | |
| Final reducer | Planetary reduction | |
| Tire | 20.5-25L-3 16PR TT | |
| Travel spped -forward | 11.5/36km/h | |
| Travel spped -reverse | 16km/h | |
| Brake system | Service brake | Single circuit caliper ,dry brake |
| Setting pressure | 0.70-0.78MPa | |
| Parking brake | Flexible shaft conrolled calipe brake | |
| Emergency brake | Flexible shaft conrolled calipe brake | |
| Steering system | Type | Hydaulic load sensor system |
| Pump | gear pump 138L/min 2200rpm | |
| System pressure | 16MPa | |
| Steering angle | ±35° | |
| cylinder type | double acting | |
| Hydarulic system | Type | Joystick control (single -lever) |
| Pump | gear pump 110L/min .2200rpm | |
| Control valve | 2 Spool (bucket & boom ) | |
| System pressure | 16MPa | |
| Cycle time (sec) | 11.5 | |
| Service refill capacity | Fuel tank | 240L |
| Hydraulic tank | 220/225(3rd spool) | |
| Crankshaft | 17L | |
| Transmission type | 46L | |
| Front axle/ rear axle | 23L | |
| OPTIONAL |
| Mechanical shift working control |
| Oil-bath air filter |
| 20.5R25 ** L-3TL |
| sliding cabin window |
| electric heating rear window |
| lockable oil tank cap |
| rear view camera |
| bucket (3 pieces cutting edges ) |
| enlarged bucket 2.5m3 |
